Would you like to have fire-safe, water- and gas tight cables / pipes penetrations?
We offer you a new generation sealing system - RISE®
You can also add or remove cables / pipes if needed, because RISE® offers
THE MOST COMPACT INSTALLATION
Successfully tested, certified and patented in many countries.
So we are at your disposal...!
RISE® system is approved by all the major global Classification Societies
There are only two different components of which the RISE penetration consists:
FRR/EHF rubber filler sleeves
For the RISE® insert sleeves, a special rubber compound was developed known as FRR/EHF (fire resistant rubber / low grade of expansion, halogen free). In the event of fire or at temperatures in excess of 200 C the FRR/EHF rubber expands from 5 up to 10 times its original volume. During the expansion of the rubber a carbonized mass is formed which has good properties of thermal insulation.
FIWA® is fire-resistant sealing putty based on a single component silicone compound.
FIWA® is:
Water-repellent.
High bonding strength.
UV- and Ozone resistant.
In the event of fire or at temperatures in excess of 200 C also the sealant expands to about 10 times its original volume. During this process a porous mass is formed which has excellent thermal insulation properties. The expansion of FIWA® is not accompanied by formation of large amounts of fumes.
It's so simple. No work for specialists.
What could be easier?
Sealant FIWA®
The only tools and accessories needed to finish the conduit are:
a compound gun,
a water spray,
a small spatula.
RISE® system is a time and money saving installation.
RISE® type EMC protects cable penetration from electromagnetic fields. The inducted interference currents are capable of affecting the performance of equipment fitted with sensitive microelectronics, such as control systems, process computers and electronic data processing systems and can even cause failure of that equipment.
What to do? Protect all the cables, which lead to the electrical installation.
RISE® system can be used for:
CABLES
The cables can be ducted through the conduit sleeve / frame in random order. A RISE® insert sleeve is applied around each cable. The remaining free space in the conduit is filled with RISE® filler sleeves type 18/12 and 27/19. Then you have to push the insert / filler sleeves into the conduit in such a way that about 20mm free space at the front is left free to apply FIWA® sealant at each side of the conduit.
The way how to install RISE® system for cables.
PIPES
The pipe can be passed through the conduit pipe in any position, provided there is enough space between the penetration and the ducted pipe.
The PP, PVC and/or other pipes can be ducted through the conduit.
The remaining free space in the conduit is filled with RISE® filler sleeves and pushed in such a way to leave about 20 mm free space for FIWA® sealant which is applied at each side of the conduit.
The way how to install RISE® system for pipes.
